Overview
True full-range performance when space won't allow a subwoofer—the CELTO PM12 G3 unleashes a commanding 600 W RMS (2400 W peak) with deep, powerful low-frequency reproduction down to 40 Hz, courtesy of advanced Transmission Line technology. This all-in-one passive loudspeaker delivers natural, incredibly holographic sound with outstanding clarity and dimensional imaging across larger areas. Ideal for multi-purpose halls, dance schools, gyms, sports arenas, and any installation where authentic full-range coverage is essential without additional bass cabinets. At its core, a premium 12" custom CELTO driver with 3" voice coil pairs…
Read the full overview
True full-range performance when space won't allow a subwoofer—the CELTO PM12 G3 unleashes a commanding 600 W RMS (2400 W peak) with deep, powerful low-frequency reproduction down to 40 Hz, courtesy of advanced Transmission Line technology. This all-in-one passive loudspeaker delivers natural, incredibly holographic sound with outstanding clarity and dimensional imaging across larger areas. Ideal for multi-purpose halls, dance schools, gyms, sports arenas, and any installation where authentic full-range coverage is essential without additional bass cabinets. At its core, a premium 12" custom CELTO driver with 3" voice coil pairs seamlessly with the acclaimed ACD44 compression driver featuring HSP annular high-strength polymer diaphragm on a proprietary rotatable 80°x50° 6th-order Polynomial horn. Exterior-grade birch plywood cabinet with tongue-and-groove assembly, with CELTO Signature Titanium finish, 15 M8 rigging points, and dual-angle 35 mm pole socket ensure rugged, versatile deployment. 97 dB sensitivity and a thunderous 131 dB peak SPL provide effortless authority with smooth on- and off-axis response throughout 40–22,000 Hz. Genuine Neutrik Speakon connectors and comprehensive bracket options simplify fixed or mobile installations. The PM12 G3 proves that genuine full-range power, holographic precision, and real-world durability can coexist in one elegantly compact package.
Specifications
- Speaker type
- Passive Full Range Speaker
- Power Handling (AES standard)
- 600 W RMS / 2400 W Peak
- Nominal impedance
- 8 Ω
- Average sensitivity
- 97 dB / 1 W / 1 m
- Maximum SPL (calculated)
- 125 dB RMS / 131 dB Peak
- Frequency response (−6 dB no preset)
- 40~22000 Hz
- Nominal directivity (−6 dB)
- 80° (H) x 50° (V)
- Cabinet
- Exterior grade Birch Plywood Tongue & Groove construction
- Cabinet finish
- Textured Waterborne Black coating Acoustic PU foam behind Front grill
- Floor monitor use
- No
- Flying hardware
- 15 M8 points
- Mounting hardware
- Ø35 mm socket (0° and 10°)
- LF
- 12" CELTO 12PF601-8
- Woofer Chassis
- Die Cast Aluminium
- Woofer Voice coil
- 3" / 75 mm
- HF
- CELTO ACD44
- HF RMS power (AES standard)
- 80 W above 1.5 kHz
- HF Exit
- 1" / 25 mm
- HF Voice coil diameter
- 1.7" / 44 mm
- HF Diaphragm
- HSP Annular (High Strength Polymer)
- Crossover
- 1.5 kHz 2-way passive network
- Connectivity
- Genuine NEUTRIK 2pcs Speakon NL4MP
- Speaker size (HxWxD)
- 620 x 348 x 405 mm
- Speaker Weight
- 24 kg
- Shipping information
- 29 kg 720 x 450 x 515 mm
- Accessories
- PM12-YOKE CPC-70 (pole bar with crank) KTV-BRKT1 (ceiling mounting bracket) WMBRKT60 (wall mounting bracket)
