Overview
10 years of stagecraft. One definitive hexagon. Ten years ago, Portman Lights set a new benchmark for stage emotion by merging classic tungsten warmth with decorative housing. Today, we present the culmination of our journey: a single, weather-sealed hexagonal cell engineered with one of the best tungsten-emulated haloLED™ FC, pixel-mapped SMESH™, and unprecedented visual depth.
3D HEXskin™ housing
IP65 fixture with a haloLED™ FC main source and an SMESH™ mesh matrix, 1600–3200 K plus RGB.
fastLINK™ quick connectors
Fixed and adjustable fastLINK™ connectors are in the box.
Specifications
- Weight (fixture only)
- 6,5 kg 14.3 lbs
- Protection rating
- IP65
- Input voltage
- 100-240 V 50/60 Hz
- Max power consumption
- 120 W
- Power connectors
- AC power in/thru: powerCON TRUE1
- Light sources
- Main: haloLED™ FC · Mesh matrix: SMESH™
- Power
- 120W WW + 90W RGB · 30W RGB
- Beam angle
- 94°
- Colour temperature
- 1600 – 3200 K · RGB
- Total luminous flux
- 3 500lm · 1 000lm
- Sections
- 1 · 13
- CRI
- > 80
- Control connectors
- DMX512, RDM, WDMX (optional)
- Control features
- 7 DMX modes (9-94 channels) RDM macros influencer/follower mode
- Additional features
- 3D HEXskin™ housing fastLINK™ quick connectors
- User interface
- OLED display
- Certificates
- CE
- Warranty
- 24 m
- What’s in the box
- Fixture AC power cord (PowerCon TRUE 1/no AC plug) User manual Fixed fastLINK™ connector Adjustable fastLINK™ connector
