Specifications
- Light sources
- 864 × 1.6 W RGBW LEDs (24 segments); 576 × 1 W CW LEDs (96 segments)
- Optics
- Pixel-mapped RGBW + CW strobe; 180° motorized tilt
- Colour temperature
- Preset CTO
- Control features
- DMX, RDM, Art-Net, sACN; 18/33/56/76/92/112/114/138/208 DMX channel modes; 16-bit electronic dimming; pixel control (3×8 RGBW, 24×4 CW); preset CTO and LED macro effects
- User interface
- Full-color 180° reversible LCD menu display
- Input voltage
- 100–240 V, 50/60 Hz
- Power consumption
- 1200 W (dynamic), 1800 W peak (strobe)
- Power connector
- Seetronic powerCON TRUE1 IN/OUT
- Control connector
- Seetronic IP65 3-pin or 5-pin XLR IN/OUT
- Rigging
- Omega bracket / truss mounting; motorized 180° tilt
- Mounting position
- Any position
- IP rating
- IP65
- Dimensions
- 493 × 175 × 400 mm (19.4 × 6.9 × 15.7 in)
- Weight
- 17 kg (37.5 lbs)
