Main and narrow source
440 W RGBWLA main source at 90°, 2000–6500 K, plus a 40 W RGBW narrow source at 3.8°. Rated IP65.
Specifications
- Weight (fixture only)
- 14 kg 30.87 lbs
- Protection rating
- IP65
- Input voltage
- 100-240 V 50/60 Hz
- Max power consumption
- 450 W
- Power connectors
- AC power in/thru: powerCON TRUE1
- Light sources
- Main source · Narrow source
- Power
- 440 W RGBWLA · 40 W RGBW
- Beam angle
- 90° · 3.8°
- Colour temperature
- 2000 – 6500 K · 6000 K
- Total luminous flux
- 8 000 lm
- CRI
- > 95 (calibrated mode)
- Control connectors
- DMX/RDM data in/thru: 5-pin XLR Firmware from flash drive: USB A
- Control features
- 8 DMX modes (8-28 channels) RDM macros influencer/follower mode CRMX (optional module)
- User interface
- OLED display highlighted touch buttons Colour Feedback System™ – fixture’s auto information status
- Certificates
- CE ROHS ETL UL UKCA
- Intelectual protection
- design patent utility patent (pending) trademark
- Warranty
- 24 m
- What’s in the box
- Fixture AC power cord (PowerCon TRUE 1/no AC plug) User manual OMNICLE™ – decorative magnetic cover
- Additional accessories
- Rigging: omega bracket with 1/4 fast locks Optics – magnetic: Diffuser 20º Diffuser 10×60º (elliptical) Micro Fresnel F220 Control features: CRMX Packing: flight case (4-units) soft case bag (1-unit)
